Description:

G-tech's LR Series stands at the forefront of lithium iron phosphate battery technology. Renowned for its exceptional performance, safety, high quality, and versatile applications, this series has garnered enthusiastic market reception. Whether powering residential solar systems, electric vehicles, or industrial applications, G-tech's LR Series batteries deliver unmatched reliability and efficiency. Join the growing number of satisfied customers who trust G-tech for superior lithium iron phosphate batteries that excel in every aspect.

Features:

1. Cells cycle times 5000 cycles(+25%C 0.5C 85% DOD)

2. Long lifespan: 5 years warranty, 10 years life design
3. 4U rack-mount chassis design is easy for parallel expansion and maintenance
4. Smart BMS system to optimize the performance
5. Communication: RS485/SNMP/Wifi/Bluetooth, Compatible with different brand of solar inverter and chargers
6. All around protection: such as SOC/SOH/ Anti-theft function etc
7. High discharge rate currents, suitable for on-grid or off-grid solar system and other loads
8. Maximum of 16 battery packs can be connected in parallel
9. With front display to know effectively the status of the batteries

10.Communicate with mainstream inverter: Growatt/Voltronic/GOODWE/Pylontech/Kstar/MUST etc.

Product Specification:

Model	LR25.6-100	LR48-100	LR51.2-100	LR48-200	LR51.2-200
Battery Type	LiFePO4	LiFePO4	LiFePO4	LiFePO4	LiFePO4
Battery Model	25.6V100AH	48V100AH	51.2V 100AH	48V200AH	51.2V200AH
Nominal Capacity(25 ℃,0.2C)WH	2560Wh	4800Wh	5120Wh	9600Wh	10240Wh
Adjustable Working Volltage(Vdc)	22.4～29.2V	37.5-53.25V	40-56.8V	37.5～53.25V	40～56.8V
Max Charge Voltage(Vdc)	28V	54.75V	58.4V	54.75V	58.4V
Max Continuous Discharge Current(A)	100A	100A	100A	200A	200A
Max Pulse Dischange Curent(A)	150A	150A	150A	250A	250A
Max Continuous Charge Curent(A)	100A	100A	100A	200A	200A
Cycle Life(25C 0.2C 80%DOD)	>5000 Cycles	>5000 Cycles	>5000 Cycles	>5000 Cycles	>5000 Cycles
Terminal	M8
Storage Duration	6 months at 25 ℃
Safety Standard	UN38.3/MSDS/CE
Communication Function	RS485/CAN(Standard)
Communication with Mainstream Inverter	Growatt/Victron/GOODWE/Pylontech/MUST etc.
Protection	Overcharge protection/Over discharge protection/Over current protection/ Short circuit protection/ Over temperature protection
WHD(Product Size)mm	L444W482H178	L516W482H132.5	L516W482H132.5	L551W482H132.5	L846W482H177
Net Weight(Kg)	27.1	42.8	44.8	84.3	88.3

Applications:

◆ Electric Vehicles

◆ Energy Storage Systems

◆ Solar Energy Storage

◆ Portable Electronic Devices

◆ Emergency Power Supply

High Capacity 12V LiFePO4 Battery for Lead Acid Replacement 0

Support and Services:

We offer technical support and services for LiFePO4 Battery Pack, including:

Assist with product selection and application

Product installation and troubleshooting

Product testing and evaluation

Product customization

Product repair and maintenance
